OPEL Series
The brake disc is simply a round plate, which also rotates when the car travels The brake calliper clamps the brake disc to generate braking force. When stepping on the brake, it clamps the brake disc to slow down or stop Brake disc has good braking effect and is easier to maintain than drum brake.
- Commodity name： OPEL Series
- 车系 ： OPEL Series
Category:
Label:
- 产品描述
-
The brake disc is simply a round plate, which also rotates when the car travels The brake calliper clamps the brake disc to generate braking force. When stepping on the brake, it clamps the brake disc to slow down or stop Brake disc has good braking effect and is easier to maintain than drum brake.
The brake disc is made of gray cast iron 250 made in China for short HT250, which is equivalent to G3000 made in the United States The requirements of the three main elements of chemical composition are: C: 3.1 ↓ 3.4 Si: 1.9 ↓ 2.3 Mn: 0.6 ↓ 0.9 Mechanical properties: Tensile strength > = 206MPa, bending strength > = 1000MPa, deflection > = 5.1 mm. Hardness requirements are between 187~241 HBS.
Brake discs are divided into solid brake discs and ventilation discs according to structure A solid brake disc is a metal disc used for braking and has no special structure The ventilated discs are divided into two types: scribed discs and perforated discs. The two treatments can improve the cooling performance of brake discs, and their thermal attenuation degree can provide better braking ability.
Brake discs can be divided into carbon fiber ceramic brake discs and metal brake discs according to different materials. However, due to the high manufacturing cost and poor braking force at low temperature, carbon fiber ceramic brake discs are still not selected by most vehicles despite their excellent thermal attenuation resistance In order to resist thermal attenuation ability, some manufacturers also carry out carbon fiber treatment on metal brake discs to improve their ability in this respect and avoid the problem of poor low temperature performance of carbon fiber ceramic materials.
Vehicle series Vehicle model Position OE # Opel series Weida 2.0 B (small) Shroud 90250546 Opel series Weida 2.0 Rear disc 4839338 Opel series Weida 2.0 C (large) Shroud 4837019/569056 Opel series VECTRA C 2.2 Rear disc 569115/46836489/9156785/9156787/93171848 Opel series Oumeijia 2.2 Shroud 90392559/569044/90344650 Opel series Oumeijia 2.2 Rear disc 90444513 Opel series Jeep Andra Shroud 96625948/4808848/20892949/55211-78J01/55211-78J00、25804049;96625948;4808848;5521178J01;5521178J00 Opel series Jeep Andra Rear disc 96625873/4804637/15223784/55611-78J00、25804046 Opel series After Yate 05/Safari 05 Shroud 569061/5391560 Opel series /After Yate 05/Safari 05 Opel Corsair (98-07) Rear disc 569109;9117772 Opel series Yate 280 diameter commonly used domestically/Kesai/Opel Safari Shroud 569060/90539466/9117678/93197592/BFR134010 Opel series /After Yate 05/Safari 05 Opel Corsair (98-07) Rear disc 569109;9117772 Introducing our revolutionary brake discs, meticulously designed to provide drivers with unparalleled performance, safety, and reliability on the road. Engineered using cutting-edge technology and premium materials, these brake discs deliver exceptional stopping power and ensure a confident and controlled braking experience.
Our brake discs are crafted from high-grade cast iron or advanced carbon ceramic composites, ensuring superior strength and durability. These materials are selected for their excellent heat dissipation properties, effectively reducing the risk of brake fade and maintaining consistent braking performance even under extreme conditions. With our brake discs, you can rely on their robust construction to withstand the demands of everyday driving and intense braking situations.
What sets our brake discs apart is their innovative design that maximizes thermal capacity. The intricate cross-drilled or slotted patterns on the disc surface enhance heat dissipation, allowing for efficient cooling and preventing overheating of the braking system. This results in enhanced brake performance, reduced brake wear, and extended service life. Say goodbye to brake fade and hello to reliable and responsive braking power.
To ensure uncompromising quality and performance, our brake discs undergo rigorous testing and adhere to strict industry standards. Each disc is precision-machined to achieve perfect balance and uniform thickness, minimizing vibrations and brake judder. This attention to detail guarantees a smooth and stable braking experience, giving you the confidence to navigate various driving conditions with ease.
Other series OE numbers can be viewed by downloading product catalog files
